Description
SPEED GATE
Glasswing
Fastlane Glasswing is an intelligent turnstile with retracting glass barriers, uniquely available in three widths. It combines advanced optical technology with elegant wing-shaped barriers for rapid throughput and intelligent tailgate detection.
- Industry-leading speed of 1 person/second
- Detects tailgaters as close as 1/4” (5mm) apart
- Compatible with Access Control, CCTV, and building management systems
Fast Acting “Angel Wing” Barriers
Fastlane Glasswing is an optical turnstile with retracting glass barriers, uniquely available in three widths. It combines advanced optical technology with elegant wing-shaped barriers for rapid throughput and intelligent tailgate detection. With Fastlane, security has never looked so inviting.
Advanced Security Technology
Utilizing cutting-edge optical detection technology for unparalleled accuracy and safety.
- High-resolution infrared matrix
- Detects tailgaters as close as 1/4” (5mm) apart
- Can differentiate between body mass and smaller objects
User-Friendly Design
Engineered for quick acceptance and smooth operation in high-traffic areas.
- Glass barrier retracts into the pedestal.
- Automatic local alarm for unauthorized entry
- Fire alarm integration for emergency egress
Flexible Integration
Seamlessly connects with existing building systems for comprehensive security management.
- Compatible with Access Control, CCTV, and building management systems
- Fastlane Connect™ ethernet communications for remote control and diagnostics that enables Web-based turnstile control from any PC, tablet, smartphone, or from Fastlane’s Multilane Controller.
- Optional visitor management input
Sustainability
- LEED Preferred Manufacturing
- Low Voltage/Low Power Consumption
- ISO 14001:2015 Accreditation
Barrier breakaway force≥ 25N (measured at 285mm from the shaft axis)
| Product Features | Glasswing |
|---|---|
| Elliptical End Compact (in inches) | 59.1 x 12.1 x 37.8 |
| Square End Compact (in inches) | 49.3 x 12.1 x 37.8 |
| Elliptical End Standard (in inches) | 59.1 x 14.6 x 37.8 |
| Square End Standard (in inches) | 49.3 x 14.6 x 37.8 |
| Elliptical End Wide (in inches) | 59.1 x 17.8 x 37.8 |
| Square End Wide (in inches)) | 49.3 x 17.8 x 37.8 |
| Available lane widths (in inches) | 21.7 (compact) / 26.0 / 36.0 (ADA) |
| Barrier heights (in inches) | 36.5 |
| Barrier breakaway force | ≥ 25N (measured at 285mm from the shaft axis) |
| Optional Locking System | Solid lock, no breakaway function |
| Tailgate detection | 1/4” |
| Pedestal Weight | Compact 176lbs / 80kg Standard 242lbs / 110kg Wide 264lbs / 120kg |
| Materials | |
| Enclosure material | Stainless steel 304, 240 grit (satin no. 4), horizontal grain |
| Barrier material | 10mm Toughened Safety Glass EN14179 / ANSI 97.1 |
| Environmental | |
| Temperature | 5 to 50 degrees centigrade |
| Relative humidity | 5 to 95% non-condensing |
| Energy consumption per lane | 295kW hours per annum |
| Ingress protection | IP20 (Internal building applications only |
| Turnstile Power Specifications | |
| Receive Gate / Transmit Gate | 24Vdc 1.3A (max) |
| Dual Gate Interlane | 2x 24Vdc 1.3A (max) |
| 24Vdc Power Supply (Included) | |
| Enclosure | Black mild steel, wall mounted, 13” x 8” x 5.5” |
| Modules | Dual or quad 24Vdc 2.5A overcurrent fold back |
| Input voltage | 100-240Vac, 60/50Hz, 5A fused spur connection |
| Outputs | 24 V DC, 60 W, 1.25 A |
| Access Control Inputs | |
| Voltage-free contact; 1mA current sense |
Entry & Exit request (NORMALLY OPEN closing for 1 second) |
| Screw terminal connector | Visitor entry (NORMALLY OPEN momentary closing contact) |
| Max conductor CSA 16AWG/ 1.5mm2 | Visitor exit (NORMALLY OPEN momentary closing contact) |
| Fire panel integration input | Opto-coupled Input12-24Vdc @ 25mA nominal |
| Ethernet connection | RJ45 TCP/IP Port |
| Access Control Outputs | |
| Voltage-free contact; Contact Rating 28Vdc 0.5A | Entry & Exit monitor (NORMALLY CLOSED opening for 1 second) |
| Screw terminal connector | Alarm 1 (NORMALLY CLOSED opening for 1 second) |
| Max conductor CSA 16AWG/ 1.5mm2 | Alarm 2 (NORMALLY CLOSED opening for 1 second) |
| System Outputs | |
| Turnstile status display | RGB LED diffused through 10mm high clear frosted acrylic |
| Alarm sounder output | 75 – 100 dB (93dB at 1 meter) |
*Fastlane logo present on left-most pedestal base. Removal available upon request.
* Due to continuous improvements, specifications are subject to change without prior notice.
